ROCKFORD FOSGATE M750-1D
Prime Marine 750 Watt Class-D Mono Amplifier Μονοκάναλος Ενισχυτής
Το M750-1D είναι υψηλής απόδοσης 750 Watt marine μονοκάναλος ενισχυτής κατηγορίας D με πλακέτα PC ποιότητας Marine, ενσωματωμένο Punch EQ, φίλτρο υπερήχων, κυκλώματα προστασίας crossover και tri-state.
Rated Power
(RMS Continuous Power)250 Watts x 1 @ 4-Ohm
500 Watts x 1 @ 2-Ohm
750 Watts x 1 @ 1-Ohm
Number of Channels1
Total Power
(Sum of Rated Power)750 Watts RMS
BridgeableNo
CEA-2006 CompliantCEA-2006 GuidelinesCEA-2006 Power Rating
250W x 1 @ 4Ω
≤1.0% THD+N
Tone Controls0dB to +18dB @ 45Hz
Signal InputLow Level: 1 RCA Pair
Speaker Output ConnectorBlock
Speaker Wire Gauge12 AWG
Heat Sink TypeCast Aluminum
Remote ControlsPunch Level Control
(when connected, is linked to "gain control" to provide remote output level)
Visual IndicatorsPower
Protect
Circuit Topology ClassClass D
Frequency Response20Hz to 250Hz +/-1dB
Dimensions (H x W x D)1.97" x 6.77" x 9.10"
(5cm x 17.20cm x 23.10cm)
Shipping Weight6.6 Lbs.
(2.99 Kg.)
Dynamic Power
(PVC/PowerCube®)308 Watts x 1 @ 4-Ohm
565 Watts x 1 @ 2-Ohm
769 Watts x 1 @ 1-Ohm
Dimensional Diagram
Efficiency (average)85% @ 4-Ohm
85% @ 2-Ohm
80% @ 1-Ohm
Crossover ControlsVariable 50Hz - 250Hz @ 12dB/octave
Signal OutputLow Level: 1 RCA Pair
Power Input ConnectorBlock
Power Wire Gauge4 AWG
CoolingConvection
